Build Guide - Calibration



                  1. Set [RISE] and [FALL] pots to '4'
                  2. Set the [CYCLE] switch down to the CYCLE mode
                  3. Select [LINEAR] mode
                  4. Set [VC RISE] and [VC FALL] to '0'
                  5. Monitor the [DC] output
                  6. Adjust p101 for output of 5Vp-p
